1、 Nitrogen compressor and expander are both adopt 1 use 1 standby, that can fully guarantee the reliability of the plant.
2、 This plant can produce nitrogen gas and a small amount of liquid nitrogen at the same time, and the liquid nitrogen came into liquid nitrogen storage tank as backup system, that can be ensure user use nitrogen freely.
3、 Compared with variable pressure adsorption(VPSA), this technical proposal design has many advantages, such as shown in table 5.1.
Table 5.1 Compare list between this technical proposal and VPSA
Item |
this technical proposal KDN-600/60Y |
VPSA
600 |
|
Nitrogen capacity (Nm3/h) |
600 |
600 |
|
Nitrogen purity |
≤5PPmO2 |
≤100PPmO2 |
|
Liquid nitrogen capacity(L/h) |
60 |
N/A |
|
Air compressor discharge capacity (Nm3/h) |
1800 |
2600 |
|
Air compressor discharge pressure (Mpa) |
0.73 |
0.85 |
|
Extraction ratio |
51.2% |
29.5% |
|
Running power
KW |
Air compressor system |
182 |
282 |
Pre-cooling system |
8 |
—— |
|
Purification system(average) |
8 |
—— |
|
Other |
3 |
10 |
|
Total |
201 |
292 |
|
Compare running power |
This technical proposal save 91kw compare with VPSA |
||
Power consumption per unit product ( kwh/Nm3N2) |
0.28 |
0.487 |
|
Other |
Running power can remain unchanged |
Running power will increased year by year |
